HMA series
Series Introduction
HMA series omni wheel can supply 1500KG payload maximum. while maintaining a high accuracy .This wheel adopts driven wheels as the supporting structure.The hub use integrated molding process, maximizing the intensity, stiffness and precision. HMA series omni wheel with rolling bearings and polyurethane roller materials can adapt to various indoor and outdoor occasions .
Parameter Comparison
- Product
- Diameter(mm)
- Wide(mm)
- Wheels
- Bearing
- Bearing Type
- Wheel Material
- Hub Material
- Hub Surface Treatment
- Mount
- Typical Middle Hole Size(mm)
- Weight(g)
- Load(kg)
| Product |  |  |
| Diameter(mm) | 310mm | 406.4（16"）mm |
| Wide(mm) | 150mm | 234mm |
| Wheels | 14 | 12 |
| Bearing | 28 | 24 |
| Bearing Type | Heavy duty rolling bearings | Heavy duty rolling bearings |
| Wheel Material | Polyurethane | Polyurethane |
| Hub Material | Aluminum | Steel |
| Hub Surface Treatment | High Temperature Painting | High Temperature Painting |
| Mount | Flange | Flange |
| Typical Middle Hole Size(mm) | 45mm | 45mm |
| Weight(g) | 16Kg | 45Kg |
| Load(kg) | 600Kg | 1500Kg |
Product Briefing
Integrated molding process hub , high intensity , high stiffness
This wheel uses integrated molding process, maximizing the mechanical properties of materials integrated molding process hub , high intensity ,high stiffness, reliable and long lifetime durable.
Rolling Bearing
Compared to sliding bearings and no bearings structure ,HMA series omni wheel use rolling bearing design . (to achieve ) It’s little friction, high precision ,high reliability ,convenient fix and it can be suitable for the continuous use.
load capacity between 0-1500KG
The load capacity of this series can be 0-1500KG.
Better passing performance
The supporting structure of driven wheel, which makes the wheel hub less likely to touch the ground, improved the ground adaptability and passing performance of the Omini wheel.
Industrial-grade quality
Design and manufacture in accordance with industry standard.
